As a Provider Admin I want to create and manage users, roles, facilities, and geographic assignments across multiple healthcare hierarchies (DH → CHC → PHC → SC), so that I can support clinical service delivery, field worker supervision, and ABDM-compliant reporting without breaking existing inventory, MMU, or van operations.

Technical Analysis Document:

http://pmp.piramalswasthya.org/confluence/spaces/AMRIT/pages/126025766/HWC+Facility+hierarchy+Route+Cause

Requirement Document (BRD):
https://pmp.piramalswasthya.org/confluence/x/GYAyBg

Description

The system must support multi-tenant, provider–state–service–scoped user management using a three-tier architecture while allowing healthcare facility hierarchy integration to coexist with the existing Main Store / Sub Store inventory model.

Users can have multiple roles, multiple facility assignments, and multi-village coverage, all governed through a central junction table (M_UserServiceRoleMapping2) and scoped via providerServiceMapID.

The healthcare hierarchy is introduced as an additive, nullable extension to the existing M_Facility entity, ensuring zero disruption to current MMU, inventory, and van workflows.

Acceptance Criteria

User Creation & Role Assignment

• Admin can create a user with basic profile details in M_User1
• Admin can assign multiple roles to the same user
• Each role assignment is scoped by providerServiceMapID
• A user can be mapped to multiple facilities via workingLocationID
• Soft deletion (deleted = true) is supported for users and mappings
• JWT-based authentication with Redis-backed session management is enforced

Facility & Healthcare Hierarchy

• Admin can create facilities using existing /createStore API
• Healthcare fields (stateID, districtID, blockID, healthcareLevel, hfrID) are optional
• Inventory logic continues using storeType
• Healthcare logic uses healthcareLevel (DH, CHC, PHC, SC)
• Existing Main Store / Sub Store mapping remains unchanged
• UI supports healthcare facility selection without affecting inventory UI

Field Worker & Village Coverage

• ASHA/ANM users can be assigned to multiple villages
• Village coverage stored in villageidDb (comma-separated)
• Field workers are linked to Subcenters via workingLocationID
• Block-level organization is supported
• Village assignments remain intact during role updates

Supervisor & Multi-Facility Coverage

• Supervisors can be assigned to multiple Subcenters or PHCs
• Supervisors may overlap across other supervisors’ facilities
• Supervision hierarchy is implicitly derived from workingLocationID
• No new hierarchy table is required for supervision logic
• Multiple mappings for the same user are supported and processed by mapRole()

Multi-Tenant & Isolation Rules

• All data access is scoped by providerServiceMapID
• Users cannot access data outside their provider–state–service boundary
• Supports multiple providers operating in the same geography
• Audit trails and soft deletion are preserved
